New Product Release | KEYTO 1212 Pinch Valve Product




Product Parameters

Valve Type

Three-Way Pinch Valve

Bore Diameter

0.5MM

Material in Contact

PEEK (Connector), FKM (Tube)

Flow Rate

CV:0.004

Power

3.5W

Temperature Setting

Ambient Temperature: 5℃~55℃

Medium Temperature: 5℃~40℃

Pressure Resistance

-75kPa~150kPa

Service Life

500W

Response Time

<40ms



Special Note: Cable length/terminal can be customized



Recommended Accessories




1/4-28 UNF Connector, Rigid Tube



Note: Parameters have been simplified and are for promotional purposes only. For detailed information, please consult our sales staff.



Product Highlights

High Durability

Developed using special materials and processes, with a lifespan of up to 500W operations.



Internal Tube Design

Utilizes an internal pinch design for a more refined and compact structure.



Flexible Switching

Three-way design allows for more flexible and diverse fluid switchovers.



Minimal Internal Volume

Internal pinch design reduces internal volume to 10μL, meeting the needs of ultra-small liquid passage.



Innovative Appearance

Adopts a new appearance design for easier and more convenient installation.



Zero Dead Volume

Uses tubing liquid passage technology to eliminate reagent dead volume.



Fast Response Speed

Set response speed<40ms under normal conditions (excluding special circumstances).



No Cross-Contamination

Tubing liquid passage technology avoids contamination caused by external contact or structural liquid accumulation.



Product Specificationspinch-valve-1212-20240830-3.jpg



Quality Assurance



Three Major Quality System Certifications

IS09001, IS013485, IS014001






Four System Platforms for Quality Assurance



  • ERP System for Order Assurance and Financial Accounting



  • MES System for Full Process Information Traceability Management



  • PLM System for Product Lifecycle Management and Process Quality Warning



  • PDM System for Product Design Documentation Sharing and Management






Five Laboratories

Reliability Laboratory, Ultra-Precision Testing Laboratory, High and Low Temperature Laboratory, Mechanical Laboratory, Salt Spray Laboratory






All series products have passed CE and ROHS certifications and have completely independent intellectual property rights.




Selection Case


Application Field: Gene Sequencing
