New Product Release: Keyto LEV1 Series Micro Solenoid Valve

Instant Wash, Powerful Drainage, Unobstructed Flow

The new generation of diaphragm design solves the complex and easily clogged conditions of various high-speed media flushing and efficient waste discharge.






Product Parameters

Type

Parameters

Valve Structure

Lever-type Solenoid Valve

Valve Type

Two-way Two-position Valve (Normally Open and Normally Closed), Two-way Three-position Valve

Number of Ports

2 or 3

Orifice Diameter

5.5mm

Flow CV Value

0.3

Applicable Media

Water, Air, Weak Acid, Weak Alkaline, etc.

Operating Environment Temperature

-10~60°C

Pressure Resistance

0~0.4MPa

Material

Valve Body: PPS, Diaphragm: EPDM

Response Time

<25ms

Rated Voltage

24V

Power

10W




Recommended Accessories




Product Highlights



Instant Wash and Strong Discharge

LEV1 series micro solenoid valve features the new generation diaphragm structure design, effectively solving complex conditions such as high-speed flushing and efficient waste discharge of various reagent media, avoiding clogging problems caused by impurities in the media.



Long-Lasting Power

LEV1 series solenoid valves can achieve an action life of over200 million times.



Ultra-rapid Response

LEV1 series solenoid valves demonstrate excellent response performance under standard environmental conditions,with a response time of <25ms.



Unobstructed Flow

LEV1 series solenoid valves are designed with large orifice, high flow capacity. The orifice diameter is expanded to5.5mm, resulting in low resistance along the path;flow capacity Cv is about0.3;flow rate is about 50mL/s (under conditions 50Kpa, 25℃, pure water).



Strong and Durable Pressure Resistance

LEV1 series solenoid valves possess excellent pressure resistance,capable of withstanding working pressures up to 0.4MPa, offering reliable and stable performance.



Corrosion-resistant Material

The LEV1 series micro solenoid valve features a PPS body, known for its excellent chemical resistance and high-temperature durability. The diaphragm is made from EPDM material, which offers superior sealing performance and aging resistance.



Quality Assurance

Three major quality system certifications: ISO9001, ISO13485, ISO14001



Four system platforms ensuring quality:

  • ERP system for order and financial management

  • MES system for full-process traceability

  • PLM system for product lifecycle management and process quality alerts

  • PDM system for design drawing data sharing and management



Five performance monitoring laboratories:

  • Reliability Laboratory

  • Ultra-Precision Testing Laboratory

  • High and Low-Temperature Laboratory

  • Mechanical Laboratory

  • Salt Spray Laboratory



Full product certifications: CE, ROHS, with complete independent intellectual property rights



Application Areas




  • In-vitro diagnostic instruments

  • Biochemical synthesis processing

  • Environmental water quality monitoring

  • Chemical materials manufacturing

  • Semiconductor cleaning and processing
